Diamondback Haanjo 7C EXP
$4,400.00
Details
Carbon frame w/ Endurance Geometry and 12mm thru-axle rear is lightweight, rugged and comfortable
RockShox Rudy XPLR 40mm travel fork to take on even more rugged terrain
- SRAM Apex AXS eTap 1x12 drivetrain components for a quiet and stable ride with rugged reliability
- SRAM Apex hydraulic disc brakes provide peerless power and control
- HED Tomcat disc wheels are fast and durable and play nice with wide tires
| FRAME SIZE | 50CM | 53CM | 56CM | 59CM |
|---|---|---|---|---|
| Rider Height | 5'4"-5'7" | 5'7"-5'10" | 5'10"-6'1" | 6'1"-6'4" |
| Bike Stand Over Height | 749.0 mm | 785.0 mm | 813.0 mm | 841.0 mm |
| Bike Seat Tube Length | 450.0 mm | 500.0 mm | 535.0 mm | 565.0 mm |
| Bike Top Tube Length | 535.0 mm | 550.0 mm | 575.0 mm | 600.0 mm |
| Bike Head Tube Length | 130.0 mm | 145.0 mm | 160.0 mm | 185.0 mm |
| Bike Head Angle | 70.0 ° | 70.0 ° | 71.0 ° | 71.0 ° |
| Bike Seat Angle | 74.5 ° | 73.5 ° | 73.0 ° | 73.0 ° |
| Bike Wheel Base | 1032.0 mm | 1039.0 mm | 1050.0 mm | 1075.0 mm |
| Bike Chain Stay Length | 430.0 mm | 430.0 mm | 430.0 mm | 430.0 mm |
| Bike Fork Offset | 50.0 mm | 50.0 mm | 50.0 mm | 50.0 mm |
| Bike Bb Height | 278.0 mm | 280.5 mm | 280.5 mm | 280.5 mm |
| Bike Bb Drop | 75.0 mm | 72.5 mm | 72.5 mm | 72.5 mm |
| Bike Stem Length | 70.0 mm | 80.0 mm | 80.0 mm | 90.0 mm |
| Bike Handlebar Width | 400.0 mm | 440.0 mm | 440.0 mm | 460.0 mm |
| Bike Crank Length | 170.0 mm | 172.5 mm | 172.5 mm | 175.0 mm |
| Bike Seat Post Length | 310.0 mm | 310.0 mm | 400.0 mm | 400.0 mm |
| Bike Stack | 579.0 mm | 591.0 mm | 609.0 mm | 632.0 mm |
| Bike Reach | 374.0 mm | 376.0 mm | 388.0 mm | 406.0 mm |
| Bike Fork Length | 425 mm | 425 mm | 425 mm | 425 mm |
Specs
| Fork | Rock Shox Rudy 40mm Travel, Maxle Stealth |
|---|---|
| Hubs | 24h Aluminum Sealed Cartridge, Center Lock, 12mm Thru-axle|24h Aluminum Sealed Cartridge, Center Lock, 142x12mm Thru-axle, Cassette |
| Rims | HED Tomcat Disc 24h, 25mm Internal Width, Tubeless Compatible |
| Stem | HED, 6061 Aluminum 3D Forged, +/-7° Rise, 31.8 Bar Bore |
| Chain | SRAM Apex, 12 Speed |
| Frame | DB Carbon Gravel Frame, Endurance Geometry, Disc Specific, w/ 142x12 Thru-axle, Top Tube Bag Mounts, Replaceable Hanger |
| Tires | WTB Raddler, Dual DNA Compound, TCS, Lightweight Tubeless Casing, 700x44c |
| Brakes | SRAM Apex, Flat Mount Hydraulic Disc, w/160mm F / 160mm R, Rotors |
| Saddle | WTB Gravelier, Cromoly Rail, 142x250 |
| Spokes | 2.0/1.8/2.0 Butted Stainless Steel |
| Headset | FSA No.42, Sealed Cartridge |
| Crankset | SRAM Apex 1 DUB WIDE, w/40t Ring |
| Seatpost | Kind Shock eTENi 27.2 Dropper, 65mm (XS,S,MD) 100mm (L,XL) travel w/KG Remote |
| Shifters | SRAM Apex AXS eTap 12 speed |
| Handlebars | HED, 7050 Aluminum 12 Degree Flare, 31.8mm Bar Bore |
| Tape/Grips | Diamondback Endurance Gel Tape |
| Brake Levers | SRAM Apex Hydraulic |
| Bottom Bracket | SRAM DUB BSA |
| Rear Derailleur | SRAM Apex AXS Eagle eTap, 12 speed |
| Accessories & Extras | Tool Kit, Tubeless Valves, Frame / Chainstay Protector |
| Cassette/Freewheel | SRAM PG-1230 Eagle 11-50t |
* Subject to change without notice.
Part Numbers
| Option | UPC | MPN | Store SKU |
|---|---|---|---|
| Dark Olive Matte / X-Small | 791964610977 | 02-760-1010 | 210000041088 |
| Dark Olive Matte / Small | 791964610984 | 02-760-1011 | 210000041089 |
| Dark Olive Matte / Medium | 791964610991 | 02-760-1012 | 210000041090 |
| Dark Olive Matte / Large | 791964611004 | 02-760-1013 | 210000041091 |
| Dark Olive Matte / X-Large | 791964611011 | 02-760-1014 | 210000041092 |
